Products Description
A soft calcium iron cored wire relates to the technical field of cored wires. The utility model comprises a steel belt ring, a filling core is fixed inside the steel belt ring, a plurality of strip grooves are arranged side by side on the inner wall of the steel belt ring, the strip grooves are made by cold rolling process, the filling core comprises an inner core wire layer and an outer core wire layer, a powder layer is arranged between the inner core wire layer and the outer core wire layer, the inner core wire layer and the outer core wire layer are both made by uniform extrusion of calcium wire and iron wire, and the powder layer is made by mixing calcium powder and iron powder. The utility model can greatly improve the softness of the cored wire by opening strip grooves on the inner side of the steel belt, thereby facilitating the bending and winding of the cored wire, and at the same time, using the inner core wire layer and the outer core wire layer to isolate the powder layer can facilitate the shaping of the cored wire, and at the same time can avoid the situation that the powder in the powder layer falls into the strip grooves to affect the softness of the cored wire, thereby solving the problem that the existing cored wire is too hard and difficult to bend and wind.
Products parameters
| Alloy Cored Wire Type | Diameter | Filling rate | Specification |
| CaSi Cored Wire | 9mm/13mm/16mm | 120/225/330 | Ca:30%min Si:55%min Al:1.5%max S:0.06%max C:1.0%max Fe:4%max P:0.05%max |
| CaFe Cored Wire | 9mm/13mm/16mm | 140/260/360 | Ca:30%min Fe:68%min Al:0.8%max |
| C Cored Wire | 9mm/13mm/16mm | 55/140/210 | C:98.5%min Ash:0.45%max V:0.4%max S:0.5%max H2O:0.3%max P:0.2%max |
| Pure Ca Cored Wire | 9mm/13mm | 58/155 | Ca:98.5%min Mg:0.5%max Al:0.5%max |
Products cooperation picture
1.A device for recovering powder from discarded cored wires comprises a base, a workbench, a feeding assembly, a translation assembly, a cutting assembly, a controller and a powder collecting box. The feeding assembly is arranged on the top of the base. The feeding assembly comprises a pressing rod, a conveying platform, a first motor and a first frame. The pressing rod, the conveying platform and the first frame are all fixedly arranged on the base. The translation assembly comprises a supporting frame, a gear set, a gear rod, a second motor, a cylinder, two gear arms and two conveyor belts. The two gear arms and the gear rod are arranged symmetrically on the same side. The output shaft of the second motor is fixedly connected to the gear set. The two conveyor belts are located between the two gear arms. The cutting assembly comprises a cover shell and a cutting platform. The utility model can recover powder from the discarded cored wires by pulling the discarded cored wires to the blade and then operating the controller. The utility model is simple to operate, saves costs, greatly improves the recovery efficiency and has environmental benefits.
