Products Description
The production process of titanium powder mainly includes the following steps: raw material preparation: select high-purity titanium metal as raw material, usually using sponge titanium or titanium alloy scrap. Pre-treatment of raw materials, such as washing, drying, etc., to remove impurities and moisture from the surface.Powder preparation: The mechanical grinding method is used to crush the titanium raw material through ball mill, jaw crusher and other equipment to obtain titanium powder with a certain particle size. Or the atomization method is used, in which the titanium raw material is melted at high temperature, and then atomized into fine droplets by high-pressure gas, and the droplets solidify into powder during the cooling process.
Products parameters
| Element | Grade 1 | Grade 2 | Grade 3 | Grade 4 | Grade 5 (Ti-6Al-4V) | Grade 23 (Ti-6Al-4V ELI) |
| Titanium (Ti) | > 99.5% | > 99.0% | > 98.0% | > 97.0% | > 99.0% | > 99.0% |
| Aluminum (Al) | - | - | - | - | 5.5-6.75% | 5.5-6.5% |
| Vanadium (V) | - | - | - | - | 3.5-4.5% | 3.5-4.5% |
| Iron (Fe) | < 0.2% | < 0.3% | > 0.30% | < 0.5% | < 0.25% | < 0.25% |
| Oxygen (O) | < 0.18% | < 0.25% | > 0.35% | < 0.40% | < 0.20% | < 0.13% |
| Carbon (C) | < 0.08% | < 0.10% | > 0.10% | < 0.15% | < 0.10% | < 0.08% |
| Nitrogen (N) | < 0.03% | < 0.03% | > 0.05% | < 0.05% | < 0.05% | < 0.05% |
| Hydrogen (H) | < 0.015% | < 0.015% | > 0.015% | < 0.015% | < 0.015% | < 0.0125% |
Products cooperation pictures
1.Powder screening: The titanium powder is screened by sieving equipment to remove too large or too small particles to obtain the powder particle size distribution that meets the requirements. Powder mixing: According to the product requirements, titanium powders of different particle sizes or compositions are mixed to obtain a uniform powder mixture. Powder molding: The titanium powder is made into a green body of the desired shape through pressing, injection molding, 3D printing and other molding processes. Sintering: The green body is sintered at high temperature, so that the powder particles are diffused and combined to form dense titanium products. Post-treatment: post-treatment of sintered titanium products, such as processing, heat treatment, surface treatment, etc., to improve their performance and quality. This process ensures that the quality and performance of the titanium powder is tightly controlled during the transition from raw material to finished product, resulting in a titanium product that meets the needs of the specific application.
